Tensar TriAx® TX190L Geogrid
Advanced TriAx Geogrid with triangular aperture technology for superior base reinforcement. Maximize aggregate interlock and pavement performance.
Product Overview
Key Features
- ✓Advanced TriAx technology with triangular apertures
- ✓Superior aggregate interlock
- ✓Reduces aggregate requirements up to 50%
- ✓Could help extend pavement life significantly
Applications
- •Roads and highways
- •Heavy traffic areas
- •Industrial paving
- •Port and rail facilities
What Is the TX190L?
The Tensar TriAx TX190L is manufactured from a punched polypropylene sheet that is oriented in three substantially equilateral directions. This process creates ribs with a high degree of molecular orientation that continues through the integral nodes, resulting in exceptional structural integrity.
The TX190L features triangular apertures with a rib pitch of 60mm (2.40 inches) and rectangular ribs. This triangular geometry distributes loads in multiple directions simultaneously, providing superior performance compared to traditional biaxial grids in applications where traffic approaches from varying angles.
Structural Performance
The TX190L achieves a junction efficiency of 93%, meaning nearly all the tensile strength transfers effectively through the grid nodes. The product has an isotropic stiffness ratio of 0.6, indicating consistent performance across different loading directions. The radial stiffness at low strain (0.5%) measures 350 kN/m.
The overall flexural rigidity of 1,500,000 mg-cm gives the TX190L enough stiffness to bridge over soft spots during installation while remaining flexible enough to conform to subgrade variations. This balance makes installation straightforward even on imperfect surfaces.
Product Durability
The TX190L offers 100% resistance to chemical degradation when subjected to aggressive environments, making it suitable for a wide range of soil conditions. It provides 70% resistance to ultraviolet light and weathering based on 500 hours of exposure testing.
Once installed and covered with aggregate, the product is protected from UV exposure and will maintain its structural properties for the life of the pavement. The polypropylene construction resists degradation from acids, alkalis, and other chemicals commonly found in soil environments.
Roll Sizes and Coverage
The TX190L comes in rolls measuring 12.5 feet wide by 164 feet long. Each roll is individually identified and labeled for quality control purposes. The triangular aperture pattern allows for efficient coverage without concerns about roll orientation during installation.
Contact us for current availability and delivery lead times. We can coordinate shipments throughout Northern Ohio and arrange for direct delivery to your jobsite.
TriAx vs Biaxial Geogrids
Traditional biaxial geogrids have rectangular apertures that provide strength in two perpendicular directions. The TriAx design with triangular apertures provides strength in six directions (three primary axes plus three intermediate directions), making it more effective when traffic loads approach from varying angles.
For parking lots, intersections, and other areas where vehicles turn and traffic patterns vary, the TriAx geometry provides more consistent reinforcement than biaxial alternatives. For straight roadways with predictable traffic patterns, biaxial products may be equally effective at lower cost.
